MINICAT GUPPY Dinghy Inflatable Sailboat
$4,500.00
The new MiniCat Guppy is based on our hugely popular MiniCat 310. MiniCat Guppy is engineered for the simplest and speediest assembly possible. With floats pre-fixed to the frame, the set-up takes just 10 minutes from start to finish. The Guppy is also exceptionally light and with grab-handles on the trampoline, it’s simple to move!
Scroll down for detailed specifications or contact us to set up a demo of one at our new Lake side facility!
THE WORLD’S FAVORITE PORTABLE SAILBOAT
MINICAT GUPPY
- 3-piece flexible composite mast
- No anchoring lines
- Main sail 4.5 m2 from Dacron (no boom)
- Aluminium ‘spine’ powder-coated frame permanently attached to trampoline
- Grey floats pre-fixed to the main frame
- Trampoline 1600x450mm with colored design, fixed with special grab-handles
- Short black keel fins, same fixing as on all other models
- No stainless-steel ropes beneath the trampoline
- Single design, single colour-scheme
- Floats fitted with stainless rings to fasten the additional front trampoline or the line when anchoring the boat
The size is based on our very popular 310 model, but with GUPPY, it is all about the simplicity and speed of assembly. With the uniquely developed design of floats pre-fixed to the frame, the set-up takes just 10 minutes from start to finish. GUPPY is also exceptionally light (just 27kg), and with grab handles on the trampoline, manipulation is easy, especially for children.
The main feature of the MiniCat GUPPY is the flexible composite mast, which is fixed simply in the frame without lines. This makes the boat much safer in strong winds, as the mast flexes and prevents the sailor from easily capsizing.
The excellent design of the sail and the lack of a jib ensure that this highly portable, lightweight dinghy sailboat appeals, especially to first-time young sailors who want to learn sailing techniques, have fun, and experience some adrenaline rushes. GUPPY is also perfect as a fun accessory for your yacht.
Features
TECHNICAL DETAILS
Length | 3000 mm | 9′ 10″ ft |
Width | 1500 mm | 4′ 11″ ft |
Height of the mast | 3950 mm | 13′ 6″ ft |
Weight | 27 kg | 59 lbs |
Diameter of floats | 390 mm | 1′ 4″ ft |
Sail | Main Sail |
Main Sail | 4.5 m2 | 48.5 ft² |
Trampoline | 1600×1450 mm | 63″ x 57″ |
Dimensions of the bag | 1650x300x300 mm | 68″ x 12″ x 12″ |
Design category | ‘D’ |
Carrying capacity | 235 kg | 529 lbs |
Number of persons | 2 People |
Time of assembly / dismantling | 10-15 min |
Hull Material | Heytex 5509 PVC |
DESIGN
FRAME & DECK
The main element of the Guppy frame is the back-bone centre frame of light-weight aluminium which is fastened by pins to the cross-section part of the floats. They are permanently attached to the floats and define their position. The trampoline is produced from high-strength woven plastic fabric and is permanently attached to the floats for speed of assembly.
The trampoline fabric sections fill the frame and are tightly secured by a threaded line. As the trampoline is taut and the frame is tight there is no need for any additional fixings.
To the rear of the frame the rudder is mounted. All parts of the frame are made of aluminum and are powder coated.
FLOATS
The Guppy is equipped with two inflatable floats 3.0 m in length and 39 cm diameter. The floats are made of reinforced Heytex 5509, highly resistant it abrasion and very hard wearing. This material is produced in Germany and production technology was adopted from the production of white-water rafts. The floats are single-chamber with a combined load capacity of 235 kg.
Both floats are fitted with three grab-handles for easy handling of the boat in and out of the water. Permanently affixed to the floats is a trampoline.
KEEL FIN
To fully enjoy sailing your Guppy you must confidently control your boat. It is imperative to minimize ‘side-sail’, especially when sailing against the wind. To achieve this detachable keel fins were designed from UV stabilised polypropylene to attach under each float. Their design and shape gives excellent performance yet still allows the boat to be sailed in very shallow water without the risk of damage. The principle of the keel fins runs across the range of MiniCat models and is a key factor in the handling characteristics of MiniCat.
MAST
The new GUPPY is featuring 3-piece flexible composite mast slotted together with no anchoring lines. The length of the assembled mast is 4,15 m. This construction ensures high flexibility and strength for ultimate safety, performance and enjoyment.
SAIL
Guppy is equipped with a single sail, without a boom for easy use. The total area of the sail is 4.5 m2. The sail material ‘Dimension Polyant ‘ is used with a surface density of 175-210g/m. The sail is ‘ all-spire ‘ construction, i.e. without a yardarm. The sail also has a window to ensure better visibility while sailing.
RUDDER
Guppy has an aluminium rudder attached to the centre of the frame. The design of the rudder allows it to be raised at a 90 degree angle, sat at the shore or in very shallow water there is no danger of damage. The rudder can be locked in both positions, raised or lowered. Thanks to the locking device the rudder can be easily arranged at the helm in two extreme positions. A tiller extension increases comfort and convenience while sailing. The tiller arm is jointed allowing full 360 degree movement.
FITTINGS
Fittings from the companies Ronstan, Seasure, Clamcleat and Suchomel are used throughout the MiniCat range of models.
All spare parts and accessories are available. See our SPARE PARTS & ACCESSORIES CATALOGUE.
As with the entire range of MiniCat models Guppy is designed and manufactured in the EU.
