Voltbike Yukon 750 Limited (2022)

5.00 out of 5 based on 1 customer rating
(1 customer review )

Starting at: $1,949.00

VoltBike Yukon 750 was engineered to upset the norm, with a never-before-seen collection of premium components. Glide into the next dimension on 750 watts of raw power, or practice self control with nine levels of electric pedal assist and the use of the signature series hydraulic disc brakes. Travel outside your comfort zone with the 17.5Ah Li-ion battery pack from Samsung.

Please Note: Each bike is individually assembled, tuned, inspected, and packed.
Lead time is currently 4 to 6 weeks. Longer delays are possible.







-

SKU: N/A Category: Tags: , , , , , , , , , , , , , , ,
Know someone who would like this? Spread the word!
Get ready to meet the 2020 edition of the fat bike legend VoltBike Yukon 750. This bike was first introduced back in 2016. During the years it got transformed and updated hundreds of times. The 2020 edition now comes with a powerful Samsung 48v 17.5Ah Lithium-Ion Battery which provides 15% more range compared to the year before. The tires got upgraded to Kenda Juggernaut K-Shield with a puncture-resistant layer so you get less flat tires and more time in the bushes. The new tire comes standard with reflective liner so you are more visible in the dark. For 2020 we also added chainring with double bash guard so your chain does not escape even in harsh riding situations. In addition, the Limited edition of Voltbike Yukon 750 comes with metal fenders, heavy-duty rear rack and rear light connected to the main battery.

Optional for Yukon 750 is a front rack that can carry up to 25lbs of additional cargo. This front rack is securely mounted with 4 bolts on the frame headset.

60-80+ km

Per Charge
32 km/h

Top Speed
750 w

Geared Hub Motor
48 v 17.5 Ah

Lithium-Ion Battery



1 Year warranty on all components standard!

Key Features

BAFANG (8Fun) is the world’s biggest maker of hub motors for e-bikes. When developing and manufacturing products, BAFANG always puts great emphasis on their reliability, quality and longevity. VoltBike Yukon 750 is using Bafang G06 series geared motor which provides 80 N.m. max torque and 750w pure power.

Samsung SDI provides high capacity cells for E-bikes. Samsung SDI’s superb cell balance technology contributes to the uniform quality of the packs and driving units, and ultimately to the quality of the e-bike. Samsung SDI’s Li-ion battery cells are preferred by high-end e-bike makers and companies that lead the e-bike market. VoltBike Yukon 750 is using Samsung INR18650-35E cells. Battery pack is 48v 17.5Ah. For full specs on Samsung INR18650-35E cells please click here.
Voltbike Yukon 750 comes standard with lockout suspension Mozo FatMan which can handle up to 5.2 inches wide tire. Designed for quick release axles and bolt on axles. 135mm dropout, 32mm stanchions, 210mm steerer tube, 90mm travel. Weight is only 7lbs.

Voltbike Yukon 750 comes with middle installed advanced LCD control panel. You can choose between 9 levels of pedal assist, walk mode, backlight brightness, max speed, switch km/h to mph and many more options.

Upgraded rear derailleur on Yukon 750 to Shimano Acera RD-410 and Shimano MF-TZ20 Tourney, 7 speed Freewheel cassette 14-28t

Equipped with super-light aluminum-alloy 6061 custom-built frame for easier pedaling.

TEKTRO Brakes are designed for superior levels of performance and durability. Tektro Auriga comp disc brakes features an open system design using non-corrosive and environment-friendly mineral oil. This is a good choice if you are looking for a quality hydraulic brake system at a good value. Fetutures dual piston design, melt forged caliper body with automatic positioning via front or rear adapters. Voltbike Yukon is using Tektro Auriga front and rear disc brakes with 180mm rotors. Read full specifications for TEKTRO Auriga here.
Puncture Resistant Tires

Yukon 750 comes equiped with tires Kenda Juggernaut K-Shield with puncture resistant layer. In addition there is reflective liner to increase night visibility.

What’s in the box?

Our bikes ship completely assembled with everything you’ll need to get up and running, including:

Helmet
HELMET
Pedals
PEDALS
Charger
BATTERY CHARGER
Multi-Tool
ASSEMBLY MULTI-TOOL

Specification

Weight
68lbs

Battery Type
48V 17.5Ah / 840Wh Lithium-ion with Samsung INR18650-35E 3400mAh cells

Motor
Bafang (8Fun) 500W (750W) Electric Brushless DC Motor G06 series. 80 N.m. max torque.

Hubset
Alloy 6061 Electric Motor

Crankset
Aluminum Alloy-6061 44T Crank, 170mm with Outer Guard

Fork
RST Guide aluminum alloy suspension with lockout function. 90mm travel. 135mm dropout. 32mm stanchions.

Shifter Type
Shimano Tourney TX50R6CT Thumb Shifter Plus 7-Speed

Chain
KMC Rust Buster. 12.7mm pin to pin center. 124 links. Total length 1547.8mm.

Freewheel / Casette
Shimano MF-TZ20 Tourney Freewheel 7 Speed 14-28T

Rear Derailler
Shimano Acera RD-410 7 speed direct rear derailler

Brakes
Hydraulic disc brakes front/rear Tektro Auriga HD-E500

Brake Lever
Tektro Auriga with safety power cut

Tires
Kenda Juggernaut 26×4 KS Shield, Wire Bead, 30 TPI casing. Puncture resistant layer.

Pedals
Wellgo LU-313 with reflectors

Derailler Guard
Rear Metal Derailler Guard

Rims
26 inch with 36 spokes

Seat
Velo Plush VL-6142

Handlebar
PROMAX ALLUMINUM ALLOY 31.8mm*22.2mm*680mm, 9 degree

Stem
PROMAX MODEL MA-596 with adjustable angle 35° – 145°. 105mm extension with bar bore 31.8mm.

Seat Post
Promax SP-252 Aluminum 6061 Alloy, 30.4mm*350mm

Bottom Bracket
Neco 910, 23.5mm + 120mm + 23.5mm

Spokes
Rear 13G 209mm, Front 13G 248mm

Front Light
Spanninga Kendo+ LED 30 Lux. Powered by the main battery and controlled from the keypad.

Rear Light
Incandecent. Powered by the main battery and controlled from the keypad.



Download VoltBike Yukon Owner’s Manual
6 pages, 500Kb, PDF

TTH

Tob Tube Length (mm)
611.9

HTA

Head Tube Angle (degree)
68.0

HTL

Head Tube Length (mm)
150.0

STA

Seat Tube Angle (degree) 73.0

STL

Seat Tube Length (mm) 483.0

CSL

Chainstay Length (mm) 465.0

WB

Wheelbase (mm)
1184.1
